PCIe Gigabit Ethernet Fiber Network Interface Card, PCI Express x1 Intel 82575EB Chipset 1000Base-SX MM Fiber NIC, Single SC Port.

The NIC-6220PF is a high-performance PCI Express multifunction network adapter, compatible with both standard and low-profile slots, designed for use in fiber-optic network environments. Based on the Intel 82575EB controller, this adapter supports 1000Base-SX operation and is suitable for high-performance desktop applications.

Key Features

Industry-Leading Performance

• Optimized for high-performance networking applications, ensuring the system I/O is not a bottleneck.
• Integrated hardware acceleration for TCP/UDP/IP checksum offload and TCP segmentation, freeing up CPU resources for application processing.

Reliability, Availability, and Serviceability

• Fault tolerance through teaming: Enables traffic rerouting from a failed port to up to seven other team members.
• Designed for demanding applications with high stability, performance, and compatibility.

Versatile Fiber Network Support

• Available with a single SC connector, supporting either multimode or single-mode fiber based on customer requirements.
• Compatible with a wide range of computers and fiber switches available in the market, making it an ideal solution for high-performance FTTD applications.

Advantages

• Intel 82575EB chipset supports enhanced functionality.
• Compatibility with all major operating systems.
• High-quality PCB design (4-layer, 1.5oz, 4mil) ensures stability, durability, and reduced resistance.
• Triple-line power supply (3.3V/2.5V/1.0V) ensures stable operation unaffected by external power fluctuations.
• Premium-quality materials and components (TI and LT power controllers) ensure a reliable working environment.
• Support for PXE and Wake-on-LAN (WOL) for advanced network management.

Standard Features

• Host Interface: PCI Express 2.0a standard.
• Intel 82575EB Controller: Integrated MAC + PHY/SERDES chip for high performance, reliability, and low power consumption.
• Fiber Gigabit Ethernet Channels: Independently support 1000Base-SX for multimode operation.
• Hardware Acceleration: Offloads tasks such as TCP/UDP/IP checksum calculations and TCP segmentation.
• Server-Class Features:
  • Link Aggregation and Load Balancing: Supports 802.3ad (LACP), Generic Trunking (GEC/FEC), and failover capabilities.
  • VLAN Support: 802.1Q VLAN tagging.
  • Priority Queuing: 802.1P Layer 2 priority encoding.
  • Jumbo Frames: Up to 16KB.
  • Flow Control: 802.3x flow control.
  • Extensive statistics for SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z, Clause 30).
• LED Indicators: Provide status for link, activity, and speed.
• Compatible with both full-height and low-profile brackets.

Specifications

General

• IEEE Standards: 1000Base-SX (850nm) for multimode fiber.
• Cable Distance:
  • Up to 220m for 62.5µm multimode fiber.
  • Up to 550m for 50µm multimode fiber.
• Connectors: SC.

Technical

• Interface Standard: PCI Express 2.0 (x1, compatible with x4, x8, x16).
• Power Consumption: +12V ±8%, +3.3V ±8%.
• Operating Temperature: -5°C to 40°C.
• Storage Temperature: -40°C to 85°C.
• LED Indicators:
  • Link (green): On when a link is established.
  • Activity (green): Blinks on activity.

Operating System Support

• Windows: 2000, XP, Vista, 7, 8 (32-bit and 64-bit), Server 2003, Server 2008, Server 2008 R2, Server 2012 R2.
• Novell Netware: 5.x, 6.x.
• Linux: Kernel version 2.6.30 or higher.
• FreeBSD: Version 7.x or higher.
• Sun Solaris x86.
• VMware ESX.
• OS Independent.
• DOS.

The NIC-6220PF Multimode Fiber Network Adapter provides a stable and high-performance solution for demanding network environments, ensuring compatibility, durability, and ease of use across a wide range of systems and configurations.
