A Pair of 10/100/1000M Single Fiber: 1-port SC/ST/FC & 4-port RJ45 BIDI WDM Fiber Media Converter.

Single Fiber 10/100/1000Base Fiber Optic Media Converters means, the 10/100/1000Base auto-sensing single fiber Ethernet media converter converts the electrical signal of a 10/100/1000 Ethernet signal from copper to fiber. This solution will offer a low-cost integration option for network managers who want to migrate from 10/100 networks to Gigabit Ethernet. Gigabit only switches can now be connected to 10/100 networks without the need to upgrade the 10/100 side, allowing network managers to add new equipment gradually.

Features

• Data rate: 10/100/1000M
• One 10/100/1000Base-T RJ-45 port autosensing featured
• One 1000Base-LX/SX Port w/ SC/ST-Type Connector
• UTP port supports: MDI / MDI-X auto crossover
• Supporting the max 1536 bytes packets
• Wavelength: 1310nm/1550nm
• The transmission of a channel signals can be completed by single fiber. It has doubled in quantity of fiber data transmission compared with twin fiber.
• Auto negotiation function allows UTP port to auto select 10/100/1000M and Full Duplex or Half Duplex
• Stand alone or card type can be chosen
• External or internal power supply

Specifications

• Operating standards: IEEE802, 3z/AB, 1000Base-T and 1000Base-SX/LX
• MAC address table: 4K
• Data buffer: 256K
• UTP Connector: RJ-45 10/100Mbps; Fiber Connector: SC 100Mbps
• UTP Cable: UTP: Cat. 5e or Cat. 6 (the max distance up to 100m)
• Fiber (single mode): 8. 3/125, 8. 7/125, 9/125, 10/125µm (the max distance up to 80km)
• Full Duplex: Supporting standard IEEE802. 3x
• LED Indicators: FX LINK, FX FDX, TP LINK, TP FDX, ACT, POWER
• Half Duplex: Back pressure
• Power: AC 90 ~ 240V; DC 5V.2A
• Working temperature: 0 ~ 50?
• Storage temperature: -20 ~ 70?
• Humidity: 5% ~ 90% (non-condensing)
