Intel PRO/1000 PT Dual Port Server Adapter, 2 RJ45, 10/100/1000Mbps, PCIe, 82571GB.
The Intel PRO/1000 PT Dual Port Server Adapter represents the fifth
generation of Intel network adapters for Gigabit Ethernet, and features
10/100/1000 Mbps self-configuration for compatibility with mixed speed
network devices. For easy installation and management, all Intel PRO
Network Connections are supported by Intel PRO Intelligent Install and
the new Intel PROSet Utility for Microsoft Device Manager. Intel PROSet
simplifies adapter installation and gives you point-and-click power to
configure and manage all your Intel PRO Network Connections for
connectivity you can count on.
Features
- Intel 82571GB Gigabit Controller
- Load balancing on multiple CPUs
- Interrupt moderation
- Compatible with x4, x8, and x16 full-height PCI Express slots
- Support for most network operating systems (NOS)
- Remote Management Support
- Category-5 unshielded twisted pair (UTP), 4-pair cabling
- RoHS compliant, lead-free technology
- Intel PROSet Utility for Microsoft Device Manager
- Advanced cable diagnostics
- Intel backing
Specifications
- Product Name: Intel PRO/1000 PT Dual Port Server Adapter
- Product Code: EXPI9402PT
- Connectors: Two RJ-45
- IEEE standards/network topology: 10BASE-T, 100BASE-TX, 1000BASE-T
- Wiring: Category-5, UTP, 4-pair
- Cable distance: 100 m in Category-5 for 100/1000 Mbps; Category-3 for 10 Mbps
- Data rate(s) supporter per port: 10, 100, and 1000 Mbps
- Bus type: PCI Express 1.0a
- Bus width: x4 Lane PCI Express, operable in x4,x8, x16 slots
- Bus speed (x1, encoded rate): 10 Gbps uni-directional; 20 Gbps bi-directional
- EEPROM-SPI and single EEPROM support: Yes
- Interrupt levels: INTA, INTB
- IEEE support: 802.3ab*
- Hardware certifications: FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
- Controller-processor: Intel 82571GB
- Typical power consumption: 4.95 W (3.3 V @ 1.5 A)
- Operating temperature: 0-55° C
- LEDs: 2 (1/port, link and speed) solid and blinking
Physical Dimensions
- Length: 12.95 cm (5.1 in)
- Width: 2.16 cm (0.85 in)
- Height of end bracket: 12.0 cm (4.725 in)
Network Operating Systems (NOS) Software Support
- Microsoft Windows* Server 2003, Enterprise, Datacenter (32- & 64-bit)
- Microsoft Windows 2000
- Red Hat Linux* 2.4x or later (32- and 64-bit)
- FreeBSD 4.x or later
- Novell Netware* 5.x, 6.x
- Sun Solaris* x86, OS 8 and later
- SCO Open Server 5, OpenUNIX 8
|
|
This EXPI9402PT is 100% genuine Intel product.
It won't have any compatibility problem with your Intel devices.
And the Intel PRO/1000 PT Dual Port Server Adapter, 2 RJ45, 10/100/1000, PCIe, 82571GB is factory new with original packaging.
Buy it now and enjoy risk free purchase with fast worldwide delivery from Compufox.com
|
|
|
|
 |
|
 |
|
