Intel Gigabit EF Dual Port Server Adapter, 2 Ports, LC, 1000Mbps, PCIe, 82576.
The Intel Gigabit ET, ET2, and EF Multi-Port Server Adapters are
Intel's third generation of PCIe GbE network adapters. Built with the
Intel 82576 Gigabit Ethernet Controller, these new adapters showcase the
next evolution in GbE networking features for the enterprise network
and data center. These features include support for multi-core
processors and optimization for server virtualization.
These
dual- and quad-port adapters provide high-performing, multi-port
Gigabit connectivity in a multi-core platform as well as in a
virtualized environment. In a multi-core platform, the adapters support
different technologies such as multiple queues, receive-side scaling,
MSI-X, and Low Latency Interrupts, that help in accelerating the data
across the platform, thereby improving application response times.
The
I/O technologies on a multi-core platform make use of the multiple
queues and multiple interrupt vectors available on the network
controller. These queues and interrupt vectors help in load balancing
the data and interrupts amongst themselves in order to lower the load on
the processors and improve overall system performance. For example,
depending upon the latency sensitivity of the data, the low level
latency interrupts feature can bypass the time interval for specific TCP
ports or for flagged packets to give certain types of data streams the
least amount of latency to the application.
Features
- High-performing, 10/100/1000 Ethernet connection
- Reliable and proven Gigabit Ethernet technology from Intel Corporation
- Scalable PCI Express* interface provides dedicated I/O bandwidth for I/O-intensive networking applications
- Optimized for virtualized environments
- Flexibility with iSCSI Boot and choice of dual- and quad-port adapters in both fiber and copper
Specifications
- Product Name: Intel Gigabit EF Dual Port Server Adapter E1G42EF
- Connector: LC
- Ports: Dual
- Data Rate Per Port: 1GbE
- Cable Medium: Fiber
- Cabling Type: MMF 62.5/50 um
- Cable Distance: 275 m at 62.5 um; 550 m at 50 um
- Network Technology: 1000Base-SX
- Bracket Height: Low Profile and Full Height
- Bus Type: PCI Express 2.0 (2.5 GT/s)
- Bus Width: 4-lane PCI Express, operable in x4, x8 and x16 slots
- Controller: Intel 82576
- Power Consumption: 2.2W
- LEDs: LINK (solid) and ACTIVITY(blinking)
- Dimension(WxL): 2.681 x 6.59 inch / 6.81 x 16.74 cm
- Product Order Codes: E1G42EF, E1G42EFBLK
|
|
This E1G42EF is 100% genuine Intel product.
It won't have any compatibility problem with your Intel devices.
And the Intel Gigabit EF Dual Port Server Adapter, 2 Ports, LC, 1000, PCIe, 82576 is factory new with original packaging.
Buy it now and enjoy risk free purchase with fast worldwide delivery from Compufox.com
|
|
|
|
 |
|
 |
|
