Vastly increase system performance by adding the speed of an M.2 SSD in any 2.5" SATA application, with the ADP-SA-M2B SATA to M.2 B-key NVMe SSD Adapter. Utilize the full potential of your SATA III controller, with an M.2 SSD reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. M.2 SSDs can also save you money by reducing your power consumption over regular platter drives.

Features

• Support M.2 drive size: 2230, 2242, 2260, 2280
• Compliant with Serial ATA Specification Rev. v3.0, backward compatible with SATA II and SATA I
• Supports B Key M.2 SSDs with SATA protocol
• Not compatible with M.2 NVMe or AHCI PCI-Express SSDs
• Supports ATA/ATAP-7 specifications
• Working temperature range: -40 ~ 85 ° C
• Operating system: Windows, MAC OS, Linux operating system
• OS independent; No software or drivers required

Applications

• Retrieve/backup data from an M.2 (NGFF) drive with a standard SATA computer
• Turn an unused M.2 (NGFF) drive into a regular 2.5in SATA solid state drive
• Access M.2 (NGFF) drives from an external source, such as a SATA drive enclosure or docking station

Specifications

• Product Type: SATA to M.2 B KEY SSD adapter
• Host Bus Interface: 7+15-PIN SATA interface
• Drive Connector: M.2 B-key slot
• Maximum Data Transfer Rate: 6 Gbps
• Operating Temperature: -40°C to 85°C (-40°F to 185°F)
• Colour: Black

Package Contents

• 1 x SATA to M.2 SSD adapter Card
• 1 x Screw package
